Synology RackStation RS820+ NAS/storage server Rack (1U) Ethernet LAN Black, Grey C3538 (RS820+)
Part number:
RS820+
EAN:
4711174723379
Payment methods
Delivery methods
> 4-core 2.1 GHz
> 2GB DDR4, up to 18GB
> Over 1,621 MB/s sequential reading
> Up to 8 drives with RX418
Ideal solutions for your business
We find the optimal solution for your business. Our sales and presales specialists select products and services for our customers every day.
Express delivery of equipment worldwide
We guarantee on-time delivery of your equipment wherever you are. We work with global partners to ensure our logistics are optimised.
Implementation support guaranteed
We offer support in implementing solutions in your business. Our qualified engineers help you manage your infrastructure effectively.
Customer first
Our RMA experts deal with complaints and equipment replacements quickly and efficiently, so that your business can run smoothly.
Description
Synology RackStation RS820+ NAS/storage server Rack (1U) Ethernet LAN Black, Grey C3538
High Performance 1U Rackmount NAS for Effective Data Storage and Management
Synology RackStation RS820+/RS820RP+ is an ideal network-attached storage solution for centralizing data management. Powered by a 4-core processor, RS820+/RS820RP+ provides both high performance and scalable storage, ideal for file sharing across different platforms and data backup. Synology RS820+/RS820RP+ is backed by Synology’s 3-year limited warranty.
High Performance Storage with Scalability
Synology RS820+/RS820RP+ is a 1U rackmount 4-bay network-attached storage solution designed for businesses requiring an effective and centralized data management. It is equipped with a 4-core processor and 2 GB DDR4 memory, expandable up to 18 GB. The PCIe 3.0 slot supports an optional 10GbE add-in network interface card, or an M2D18 M.2 SSD adapter card4, where the M.2 NVMe/SATA SSD cache can be used to boost system random IOPS.
With Link Aggregation enabled in a 10GbE environment, RS820+/RS820RP+ delivers high sequential throughput at over 1,621 MB/s reading and 599 MB/s writing2. Storage capacity of RS820+/RS820RP+ can be further expanded with one optional Synology Expansion Unit RX4183, providing a raw capacity of up 128 TB with 8 drives in total.
Ultimate Backup Solution
RS820+/RS820RP+ integrates various backup applications to safeguard your important data on any devices with an intuitive user interface and durable storage technologies.
- Workstation/Server/Virtual Machine/SaaS backup: Active Backup for Business centralizes backup tasks for virtual machines, Windows PC, servers, and rsync/SMB file servers and offers various recovery options to ensure lowest RTO. Active Backup for Office 365/G Suite is an on-premises backup solution for public clouds with a centralized dashboard, optimizing storage efficiency through the single instancing and block-level deduplication technology.
- NAS backup: Hyper Backup comprehensively backs up your data to a local shared folder, an external device, another Synology NAS, an rsync server, or Synology public cloud service, Synology C2 Backup5, to ensure data safety and availability can be achieved when a disaster happens
- Computer backup: Synology Drive Client backs up your Windows, Mac, and Linux desktop devices to safeguard important computer files. RS820+/RS820RP+ is also compatible with Time Machine, allowing you to effortlessly back up your Mac to Synology NAS.
Btrfs: Next Generation Storage Efficiency
RS820+/RS820RP+ introduces Btrfs file system, bringing the most advanced storage technologies to meet the management needs of modern business:
- Advanced snapshot technology provides schedulable and near-instantaneous data protection of share folders and iSCSI LUNs.
- File and folder level data restoration brings great convenience and saves time for users who wish to restore only a specific file or folder.
- Flexible Shared Folder and User Quota System provide comprehensive quota control on all user accounts and shared folders.
- File self-healing allows Btrfs file system to auto-detect corrupted files with mirrored metadata, and to recover broken data using the supported RAID type of volumes, including RAID1, 5, 6, and 10.
Reliability, Availability, and Disaster Recovery
System reliability is critical for business everywhere. RS820+/RS820RP+ responds to these concerns with wide-ranging availability and redundancy features:
- Synology High Availability ensures seamless transitioning between clustered servers in unexpected disasters and ensures that your services remain online.
- Snapshot Replication provides schedulable, near-instantaneous data protection, ensuring that your business documents in shared folders, virtual machines in iSCSI LUNs, or dockerized application data remain safe and available in a disaster.
- Redundant power supplies (RS820RP+ only), system fans and network ports with failover support ensure continual service uptime.
- High reliability system design, including fan-less CPU heat sink and passive cooling technology, prevents single points of failure.
- Optional 5-year warranty is available in select regions.
Multimedia
Leaflets:
Manual (PDF):
Specifications
Ports & interfaces
eSATA ports quantity
1
Ethernet LAN (RJ-45) ports
4
PCI Express x8 (Gen 3.x) slots
1
USB port
Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
Processor
Processor manufacturer
Intel
Processor socket
BGA 1310
Processor family
Intel Atom®
Processor lithography
14 nm
Processor threads
4
Processor frequency
2.1 GHz
Maximum internal memory supported by processor
256 GB
Processor model
C3538
Processor operating modes
64-bit
Processor boost frequency
2.1 GHz
Processor cache
8 MB
Processor cache type
Smart Cache
Thermal Design Power (TDP)
15.0000
CPU configuration (max)
1
Tjunction
100 °C
PCI Express slots version
3.0
Tcase
87 °C
Stepping
B1
Conflict-Free processor
Yes
Processor codename
Denverton
Processor code
SR3L7
Processor package size
34 x 28 mm
Processor cores
4
Performance
Type
NAS
Number of users
2048 user(s)
Device class
Small & Medium Business
Security algorithms
HTTPS, SNMP, SSH, SSL/TLS
Browser supported
Chrome, Firefox, Edge, Internet Explorer 10 onwards, Safari 10 onwards, Safari (iOS 10 onwards), Chrome (Android 6.0 onwards)
Backup function
Yes
Multilingual support
Yes
Access Control List (ACL)
Yes
Web-based management
Yes
Third-party support
Yes
Noise level
27.0000
Built-in iTunes server
Yes
Hot spare
Yes
On/off switch
Yes
Remotely operated
Yes
Share folder
512
Snapshot
Yes
Reset button
Yes
Network
Supported network protocols
SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
Ethernet LAN data rates
1000 Mbit/s
Ethernet LAN
Yes
iSCSI support
Yes
Load balancing system
Yes
Wake-on-LAN ready
Yes
Wi-Fi
No
Link aggregation
Yes
Memory
Internal memory type
DDR4
Memory slots
1
Internal memory
2 GB
Maximum RAM supported
18 GB
Storage
Storage drive capacity
0 GB
Storage drives installed
No
RAID support
Yes
RAID levels
0, 1, 5, 6, 10, JBOD
Maximum supported storage capacity
64 TB
Online RAID migration
Yes
Hot-swap drive bays
Yes
Total installed storage capacity
0 TB
Installed storage drive type
No
Supported storage drive types
HDD & SSD
Storage drive sizes supported
2.5, 3.5
Supported storage drive interfaces
Serial ATA III
Number of storage drives supported
4
Supported file systems
BTRFS, ext4
Processor special features
Intel® AES New Instructions (Intel® AES-NI)
Yes
Execute Disable Bit
Yes
Maximum number of PCI Express lanes
12
Intel Secure Boot Technology version
1.00
Intel Virtualization Technology (VT-x)
Yes
Memory types supported by processor
DDR4-SDRAM
Intel QuickAssist Technology
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel Secure Boot
Yes
Intel® Secure Key
Yes
Intel® Hyper Threading Technology (Intel® HT Technology)
No
Intel Secure Key Technology version
1.00
Intel VT-x with Extended Page Tables (EPT)
Yes
Embedded options available
Yes
Intel® Turbo Boost Technology
No
Intel® OS Guard
Yes
Design
Chassis type
Rack (1U)
Product colour
Black, Grey
Fan diameter
40 mm
Cooling type
Active
Fan diameter 2
40 mm
LED indicators
Alarm, Power, Status
Number of fans
3 fan(s)
Operational conditions
Storage temperature (T-T)
-20 - 60
Operating altitude
0 - 5000
Operating relative humidity (H-H)
5 - 95
Operating temperature (T-T)
0 - 35
Packaging content
Cables included
AC
Quick installation guide
Yes
Technical details
Compliance certificates
RoHS
Sustainability certificates
RoHS
Certificates
Certification
EAC
VCCI
CCC
RCM
KC
FCC
CE
BSMI
Software
Windows operating systems supported
Yes
Mac operating systems supported
Yes
Operating system installed
DiskStation Manager
Power
Number of power supply units
1
Power supply unit (PSU) capacity
150.0000
Power consumption (HDD standby)
20.9600
AC input voltage
100 - 240 V
Power supply location
Built_in
Power consumption (typical)
37.9400
AC input frequency
50 - 60 Hz
Weight & dimensions
Depth
492.6 mm
Width
480 mm
Height
44 mm
Weight
6400 g
Other features
Compliance certificates
RoHS
Digital Living Network Alliance (DLNA) certified
Yes
Certification
EAC
VCCI
CCC
RCM
KC
FCC
CE
BSMI
Processor ARK ID
97929
Logistics data
Harmonized System (HS) code
84714100
Product safety
Manufacturer's data
Name
Synology Inc.
Address
9F., No.1, Yuandong Rd., Banqiao Dist., New Taipei City 220632, Taiwan
Website
https://www.synology.com/
Email
https://www.synology.com/company/contact_us
Responsible entity
Name
Synology GmbH
Address
Grafenberger Allee 295, 40237 Düsseldorf, Germany
Website
https://www.synology.com/
Email
SKU:
1033549
